Input (PV)
Max. PV input power
7 kW
Max. PV Input Voltage
550V
Start Voltage
120V
MPP Voltage Range
125V ~ 550V
Rated MPPT Voltage Range
360V
Max. PV Input Current
14A
Number of MPP Trackers / String per MPPT
2 / 1
Output (AC)
Max. Output Current
21.7A
Rated Power
5kVA
Rated Voltage
230V, L + N + PE
Operating Voltage Range
180V ~ 280V
Frequency
50Hz / 60Hz
Power Factor
1 (0.99 lagging to 0.99 leading)
THDi
<3%
Output (EPS)
Rated Power
5kVA
Rated Voltage
230Vac
Rated Current
21.7A
Rated Frequency
50Hz / 60Hz
Automatic Switching Time
<20ms
Overload Capacity
110%, 60s / 120%, 30s / 150%, 10s
THDU
<2%
Battery
Battery Voltage Range
40V ~ 58V
Max. Charging Voltage
58V
Charge / Discharge Current
95 A / 110 A
Battery Type
Lithium / Lead-acid
Communication
CAN / RS485
Efficiency
Max. DC Efficiency
97.60%
European Efficiency
97%
MPPT Efficiency
99.90%
Battery Charge/Discharge Efficiency
95.5% / 95%
Communication
Display
LCD
Communication
Standard: RS485 / CAN / DRM
optional: Wi-Fi / LAN
Standard Compliance
Certificates
CE, TÜV, SAA
General Data
Dimensions (W x H x D)
550 x 515 x 200 mm
Weight
26 kg
Operating Temperature
-25°C to +60°C
Cooling Method
Natural cooling
Protection Rating
IP65
Noise Level
<35dB
Max. Operating Altitude
5000m (derating above 2000m)
Relative Humidity
0–95% (non-condensing)
Topology
Transformerless
Standby Power Consumption
＜3W
